IC TDA8735 PHILIPS

QUICK REFERENCE DATA
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
V cC1
supply voltage (pin 3)
4.5
5.0
5.5
V
Vccz
supply voltage (pin 16)
V cc1
8.5
12
V
I CCt
supply current (pin 3)
outputs unloaded
12
20
28.
MA
Icc2
supply current (pin 16)
outputs unloaded
0.2
0.5
1
MA
f i(irax)
maximum input frequency
30
MHz
512
kHz
t i(min)
minimum input frequency
30
500
mV
V i(ma)
input voltage (RMS value)
P tot
total power dissipation
0.14
W
Tan
operating ambient temperature
-30
+85
C
ORDERING INFORMATION
TYPE NUMBER
PACKAGE
NAME
DESCRIPTION
VERSION
TDA8735
DIP16
plastic dual in-line package 16 leads (300 mil) long body
SOT38-1
TDA8735T
SO16
plastic small outline package: 16 leads body 7.5 mm
SOT162-1
