Fractal Design Adjust R1 Controller

Adjust R1

For full manual control over your Fractal Design Prisma AL Series fans and other standard 5V addressable RGB devices

• Simple, intuitive controls
• Compatible with standard 5V ARGB LED fans, strips, and devices
• Integrated magnets for convenient placement on any steel case

Manual control for your Prisma AL-fans

A single Adjust R1 provides easy software-free control, customization, and synchronized effects for several fans, LED strips and other ARGB devices in daisy-chain or Y-cable configurations.

Customize colors, configure brightness, and set color cycling modes with a variety of pulse and motion effects

Compatible with standard 5V ARGB LED fans, strips, and devices

Integrated magnets for convenient placement on any steel case and includes Y-cable and adapters

Preset color, color cycle, custom color, long and short rainbow modes

Eight color presets and five brightness levels with six pulse and motion effects

Remembers settings when powered off



Specifications

Compatibility

5V Addressable RGB devices with standard 3-pin connector. Note: The Adjust R1 is NOT compatible with Celsius+

Color modes

Preset color: Set all LEDs to red, green, blue, orange, cyan, yellow, purple, or white Color cycle: All LEDs change color in unison Custom color: Freeze color cycle mode on the exact color of your choice Long rainbow: Colors animate in a long sequence Short rainbow: Colors animate in a quick succession

Brightness settings

5 levels

Pulse and motion effects

On (constant brightness), Slow breathing effect, Fast breathing effect, Slow single pulse sequence, Fast single pulse sequence, Slow marquee chasing effect, Fast marquee chasing effect, Off (LEDs disabled)

Maximum load

2.6 A

Unit dimensions (LxWxH), Excluding cable

45 x 17 x 8 mm

Net weight

14 g

Other

Package contents

Adjust R1 RGB Controller, RGB Y-cable (female-to-female), 2 x Male-to-male adapters

Package dimensions (LxWxH)

134 x 134 x 33 mm

Package weight

70 g

EAN

7340172701576

UPC

843276101572

JAN

4537694262743

Product code

FD-ACC-ADJ-R1-BK
